The EPSolar – EPEver XTRA2210N is a 20 Amp MPPT charge controller with a build-in LCD display that can be used to change or set the charge parameters and show real-time production information. The controller can be used with 12 & 24 Volt battery banks. The solar DC input Voltage can be anywhere between the battery Voltage + 2 Volt, up to 100 Volt maximum open Voltage. The charge controller takes care of converting the Voltage down to the battery charge Voltage, and at the same time the current is converted up proportionally, up to 20 Amp maximum. It is entirely possible to oversize the solar PV input Wattage, the EP Solar charge controller will simply clip the output at 20 Amp if there is enough sunlight to produce that much (or more). The XTRA series charge controllers provide excellent value-for-money!
An USB-to-RS-485 cable can be used to connect the charge controller to a computer. EP Solar has software available to monitor and change settings of the charge controller via a computer.
An optional external battery temperature sensor, is available as well.
If a remote display/controller is needed the .
A load controller is built into the XTRA2210N, to provide a variety of on/off selections for lights (i.e. ‘on’ at dusk for XX hours, then ‘off’, and ‘on’ again YY hours before dawn, until dawn).
EP Solar sells their charge controllers under the “EPEver” brand name. That is the name you will see on the box, the charge controllers are all made by EP Solar.
Models
XTRA2210N-XDS2
XTRA3210N-XDS2
XTRA4215N-XDS2
Nominal system voltage
12/24V
Battery type
Lead-acid (Sealed/Gel/Flooded)/Lithium (LiFePO4/Li(NiCoMn)O2)/User
Rated charge current
20A
30A
40A
Rated discharge current
Rated charge power
260W/12V
520W/24V
390W/12V
780W/24V
520W/12V
1040W/24V
Max. PV open circuit voltage
100V (At minimum operating environment temperature)
92V (At 25? environment temperature)
150V (At minimum operating environment temperature)
138V (At 25? environment temperature)
MPP voltage range
(Battery voltage+2V)~72V
(Battery voltage+2V)~108V
Equalization voltage
Sealed:14.6V,Flooded:14.8V,User-defined:9-17V
Boost voltage
Gel:14.2V,Sealed:14.4V,Flooded:14.6V,User-defined:9-17V
Float voltage
Gel/Sealed/Flooded:13.8V,User-defined:9-17V
Enclosure
IP33
Communication interface
RS485(RJ45)
Grounding
Common negative
Dimensions(LxWxH)(mm)
175×143×48
230×165×63
255×187×75.7
Net weight
0.57kg
1.31kg
2.07kg
